How to Install MISP: Powerful 7-Step Docker Guide for Kali

cyber security
how to install misp

Installing MISP, the Malware Information Sharing Platform, is vital for both professionals and enthusiasts in the cybersecurity domain. This guide describes the complete installation process using Docker Compose on a Kali Linux system. We will walk through the setup process on your Kali Linux until the MISP instance is operational and ready for access. You will gain insights into the installation processes of MISP and the efficiencies attained through containerization. After following these instructions, you will have MISP installed and will be able to take advantage of its powerful threat intelligence features.

Table of Contents

Introduction: How to Install MISP

“How to install MISP” is an often-searched topic among individuals and teams working in the cybersecurity space. The Malware Information Sharing Platform (MISP) is an open-source initiative created to facilitate the sharing, storing, and correlating of indicators of compromise (IOCs) and threat intelligence. MISP allows organizations to collect, process, and analyze data from diverse sources. It provides rich context around threat actors as well as their tactics, techniques, and procedures (TTPs). Grasping how to install MISP aids in developing a proactive threat intelligence capability. In this guide, we will focus solely on installing MISP with Docker on Kali Linux.

Why Install MISP

There is no doubt that installing MISP enhances your cybersecurity posture. It consolidates your threat intelligence data, storing it in one location. The collection, analysis, and dissemination of critical threat information is streamlined with MISP. Timely sharing of intelligence prevents attacks and detects intrusions within the network. The platform supports automated data extraction from a variety of threat feeds and collaborative security team analyses. Having control over the installation process gives you control over your intelligence ecosystem, empowering your organization to adapt to advancing cyber threats. Docker streamlines how to install MISP by taking care of its many interrelated dependencies.

Prerequisites: Before You Install MISP on Kali Linux

Knowing how to install MISP via Docker on Kali Linux requires you to set up your environment first. This preparation reduces the chances of later complications during the installation process.

System Requirements

MISP might strain your system’s resources, especially when it comes to processing numerous data feeds or performing extensive data correlations.

  • RAM: 8GB is the bare minimum, while 16GB or more is recommended, especially for the Elasticsearch component. Having more RAM will increase system responsiveness.
  • CPU: 2 CPU cores is the bare minimum, but it is recommended to have 4 or more to improve processing speed and handle parallel work within MISP and its supporting services.
  • Disk Space: You should allocate at least 100GB of disk space and strongly consider using an SSD (Solid State Drive) over an HDD (Hard Disk Drive) as SSDs significantly enhance the performance of databases and container I/O operations. Responsive and efficient MISP instances depend on SSDs.

Operating System: Kali Linux

At the moment, this guide aims to walk you through the installation steps of MISP on Kali Linux.

  • Kali Linux: Not often recommended as a production server,Kali Linux shines in penetration tests and digital forensics. Its rolling release model and focus on offensive security tools can sometimes lead to less stability compared to dedicated server distributions like Ubuntu Server LTS or Debian.
  • Lab / Learning Environment: The process of “How to install MISP on Kali Linux” is best suited for learning purposes or for building a personal lab environment. A more stable server edition is recommended for longer deployment and production systems for added reliability and security.
  • System Update: Prior to initiating any activities, confirm that your installation of Kali Linux is fully up to date.

Fundamentals of Docker for MISP Installation

MISP installation and operations make extensive use of Docker and Docker Compose.

  • Docker: Enables the creation, delivery, and execution of software in containers. Containers are self-sufficient, lightweight software packages that can be executed independently and that incorporate everything necessary to run a specific program.
  • Docker Compose: This is designed for defining and managing multi-container Docker applications. It uses a YAML file to configure its services. With a single command, all services from the defined configuration can be created and started. MISP’s official Docker installation uses Docker Compose to manage all its components (MISP core, MariaDB, Redis,Elasticsearch, etc.)
  • Advantages: Streamlined dependency management, consistent environments, and simplified updates are just some of the advantages that Docker offers to users. A great deal of the complexity of needing to set up each component required by MISP is mitigated with the help of Docker.

Comprehensive Guide: Install MISP on Kali Linux Using Docker Compose

This guide will walk you through the steps needed to install MISP on your Kali Linux system using the recommended installation method that uses Docker Compose. This method will give you MISP in a self-contained, portable box.

1. Upgrade Your Kali Linux System

It is important in this case that you remember to upkeep your Kali Linux system as every operating system in existence. It is equally vital to ensure that your system is devoid of any and every possible conflicting issue.Boosted security is another bonus added.

sudo apt update
sudo apt full-upgrade -y
sudo apt autoremove -y
sudo apt clean
sudo reboot # Restart if significant system libraries or the kernel were updated

The command plays a very important role for people using Kali when it comes to managing gigantic package shifts Having completed the Kali Linux full cycle running by a reboot guarantees all the steps have been completed.

2. Install Docker and Docker Compose on Kali

This section is especially tailored for the ease of people willing to practice “How to install MISP”. As long a Docker and Docker Compose are installed, one will be able to practice without a hitch.

sudo apt install -y docker.io docker-compose
sudo systemctl start docker
sudo systemctl enable docker
sudo usermod -aG docker $USER
newgrp docker

These commands will install and configure the Docker daemon and Docker Compose for use. The commands also enable the Docker service to start on system boot.Joining your user to the docker group means you will be able to execute Docker commands without the need for sudo. Thenewgrp docker command makes this change available at the session level. Check if Docker is running with:

docker run hello-world

You should be greeted with a message that confirms everything is working asexpected.

3. Retrieve the MISP Docker Files

The official MISP project offers Docker Compose files that describe all requisite services to execute a complete MISP deployment. You will clone this repository.

git clone https://github.com/MISP/misp-docker.git
cd misp-docker

This downloads the misp-docker repository to your current working directory. Now you change into that directory, and all subsequent Docker Compose commands will be run from there.

4. Set Up MISP Docker Environment Configuration

The example environment file is provided as .env.example within the repository. You need to copy the example and tailor it to your needs.These files contain sensitive information such as credentials and resource allocation details for MISP’s services, making them critical to the deployment.

cp .env.example .env
nano .env

You will observe several variables inside the .env file. Make sure to note the following:

  • MISP_DB_PASSWORD: Set a strong, unique password for the database user associated with MISP.
  • MISP_REDIS_PASSWORD: Set a strong password for Redis.
  • MISP_API_KEY: Configure a strong API key for initial access which will be used by the MISP platform container to communicate with the database.
  • BASE_URL: Change this to the Kali Linux IP or domain name (e.g http://192.168.1.100 orhttps://misp.local).
  • ELASTIC_MEMORY_SIZE: Configure this according to your RAM. With 16GB RAM, you might set it to 8g or 8192m. Remember, ElasticSearch uses a lot of memory.

Make sure to save and close the .env file. These settings are critical for your MISP instance to function properly. Docker Compose reads these settings during the build and start process for the containers.

5. Utilize Docker Compose to Run MISP Containers

You can now start all the MISP services with the configured .env file. The command will pull the necessary Docker images and create the containers based on the definitions provided in the docker-compose.yml file.

docker compose pull
docker compose up -d

The commands docker compose pull and docker compose up -d are both critical for the process. The former ensures that you have the latest versions of the Docker images while the latter starts all the services in detached mode (-d) remeaning they will run in the background. On the first run, this process can take quite a while as it downloads several large Docker images such as MISP,MariaDB, Elasticsearch, Redis, and MinIO.

Watch the container startup progress with the following commands:

docker compose ps
docker compose logs -f

The command docker compose ps shows the status of your running containers while docker compose logs -f will show real-time logs from all services. Please wait until all services including misp, mariadb, redis,elasticsearch, and minio are “running” or“healthy”.

6. Conduct Initial MISP Configuration Within the Container

After the containers are up, the next step is to run some initial setup scripts within the MISP application container. That involves running the necessary migrations and installing the PHP dependencies needed.

The following command does just that:

docker compose exec misp bash -c "sudo -u www-data php /var/www/MISP/app/Console/cake schema update"

Once you see the prompts, just type ‘y’ followed by hitting Enter to confirm for each table creation.

docker compose exec misp bash -c "sudo -u www-data php /var/www/MISP/app/Console/cake Migrations.Migration run all"
docker compose exec misp bash -c "sudo -u www-data /usr/local/bin/composer install --no-dev"
docker compose exec misp bash -c "sudo -u www-data php /var/www/MISP/app/Console/cake build"

The aforementioned commands perform specific tasks within the MISP container. The schema update and Migrations.Migration run all commands are responsible for initializing and updating the MISP database schema. The composer install command ensures all required PHP libraries are installed within the container.
Furthermore, the build command processes different MISP assets.

7. Set Up Your MISP Admin User Accounts

At this point, you can proceed to configure an administrator account so that you can log into the installed MISP instance.

docker compose exec misp bash -c "sudo -u www-data php /var/www/MISP/app/Console/cake user add"

Follow the prompts:

  • Assign the admin user’s email (e.g., ad***@*****le.com).
  • Choose a strong password.
  • Assign an organization (e.g., “admin”).
  • Last but not the least, important to mark this user as ‘admin’ on the role
    selection prompt.

Make sure you note down the email and password credentials you defined for the administrative user. These details will allow you to access the MISP web interface.

Your MISP instance should be fully operational after completing the Docker Compose installation and setup steps.

  1. Open any web browser.
  2. Go to the IP address or domain name that you configured asBASE_URL in the .env file (e.g.,http://192.168.1.100 or https://misp.local).
  3. You should see the MISP login page.
  4. Log in using the email and strong password you set for the admin user in
    step 7.

You have successfully learned how to install MISP using Docker Compose on your Kali Linux machine. Now, you can explore the platform, add feeds, and utilize its threat intelligence capabilities.

Securing MISP for Live Deployment

If deploying MISP in a production environment, the following security hardening measures will be vital.

  • HTTPS: Always enable HTTPS (SSL/TLS) for your MISP instance using Nginx or Apache as a reverse proxy. All traffic to and from MISP will be encrypted.
  • Firewall: Implement strict firewall rules. Limit access to MISP to the bare minimum of port 443 for HTTPS from whitelisted (trusted) IP ranges.
  • Authentication: Set robust password policies and consider enabling Multi-Factor Authentication (MFA) for MISP authenticated users.
  • Updates: Continuously refresh the Docker images as well as update the MISP core that is running within the container.
  • Backups: Enforce a solid backup policy for your MISP database along with configuration settings.
  • Resource Usage: Keep track of the resource consumption of your Docker containers, specifically Elasticsearch and MariaDB, to optimize for better performance.

All the steps outlined above are important for the protection and cybersecurity of your threat intelligence platform. This complements the policy on how to install MISP securely.

Troubleshooting Issues Related to Installing MISP through Docker

Installing MISP with Docker may not be completely trouble-free; there are problems you may need to deal with. Below is a list of common problems with a solution for each.

  • Containers Not Starting (or Exiting): Check the container status with docker compose ps, then docker compose logs -f for specific errors pertaining to that container. Look for port conflicts or other services that may be running and competing for the same ports.
  • Blank Page or 500 Error: This is often linked to MISP application container issues. Run docker compose logs misp and check for error messages. Confirm your .env file has the
    appropriate credentials with the database along with an accurate BASE_URL.
  • Database Connection Issues: Check that your mariadb container is not only running but is healthy as well. Look into MISP container logs for database connection problems. Make sure you are using the right MISP_DB_PASSWORD in your .env file.
  • Elasticsearch Problems: When Elasticsearch does not start . it has a high probability of being linked to insufficient memory. Check your host’s RAM and confirm ELASTIC_MEMORY_SIZE in your .env file. Review docker compose logs elasticsearch.
  • Permission Errors: While working under Docker’s isolation,check that the misp-docker folder where the docker-compose.yml and .env files are located are accessible by your user.
  • docker compose command not found: Verify if you added the user to the docker group as this requires logging out and in. If the issue persists, try sudo docker compose.

Self-discipline along with checking the logs are the most important things when it comes to troubleshooting while installing MISP.

Managing Your MISP Installation with Docker: Maintenance and Updates

After the installation of the system, there is a crucial first phase which should be respected which consists of self-discipline, if you want your system to remain protected and serviced. Downloading the official images of MISP and
its dependencies should be done regularly.

cd misp-docker # Change directory to your misp-docker folder
docker compose pull
docker compose up -d --remove-orphans # Fetches new images, updates containers and deletes obsolete images.

Even while the containers are active, MISP performs internal updates, and they can be performed anytime within the container.

docker compose exec misp bash -c "sudo -u www-data php /var/www/MISP/app/Console/cake Migrations.Migration run all"
docker compose exec misp bash -c "sudo -u www-data /usr/local/bin/composer install --no-dev"
docker compose exec misp bash -c "sudo -u www-data php /var/www/MISP/app/Console/cake build"
  • Operating System Updates: sudo apt update && sudo apt full-upgrade -y will keep your Kali Linux system up to date.
  • Backups: Make it a habit to back up the misp-docker directory and, in particular, the directory that contains the database data volume, which is often defined in the docker-compose.yml file as a named volume or bound mount.

Conclusion: Achieving Proficiency in Installing MISP via Docker

The ability to install MISP on Kali Linux using Docker Compose offers an effective way to deploy a sophisticated threat intelligence platform. Kali is optimally used in a controlled lab environment, and the use of containers adds reliability and ease of management. MISP is an essential tool for cybersecurity professionals as it supports proactive threat detection, contextual analysis, and information sharing. Now that you have a Dockerized MISP instance, you are able to ingest, analyze, and share critical intelligence to greatly enhance your understanding of prevailing threats. Dive deeper into MISP’s many functions and consider expanding the community around threat intelligence.

Installation of MISP: Frequently Asked Questions

  1. How can a novice on Kali install MISP?

    For novices on Kali, the MISP installation route through Docker and Docker Compose is convenient as it manages intricate dependencies automatically.

  2. What are the minimum hardware requirements to install MISP via Docker?

    When configuring MISP with Docker, ensure you have at least 8GB RAM, 2 CPU cores, and 100GB of SSD storage. Additional resources will significantly enhance performance.

  3. Why use Docker to install MISP instead of manual installation?

    Employing Docker to set up MISP enhances the installation process by removing the difficulty of dependency isolation, using the provided methods on upgrade and backup, and simplified environment consistency.

  4. Can I install MISP for production use on Kali Linux with Docker?

    Although it is technically feasible, deploying a MISP production instance on Kali Linux is not advisable. Kali is better suited as a learning or lab environment due to its rolling release nature.

  5. How do I prepare Docker and Docker Compose for installing MISP?

    On Kali Linux, the prerequisites include: installing the docker.io and docker-compose packages, followed by commencing and enabling the Docker service.

  6. In what location can I locate the configuration files pertaining to Docker for the MISP Installation?

    You will clone the official misp-docker repository which includes necessary files to install MISP, such as docker-compose.yml and .env.example.

  7. What are the crucial settings in .env that I prep prior to installing MISP?

    Some critical settings highlighted in .env file are: database and Redis passwords, a MISP API key, BASE_URL which is set to the server IP or domain, and ELASTIC_MEMORY_SIZE.

  8. What will I do to start the MISP containers after .env file configuration?

    From the misp-docker directory, execute docker compose pull and docker compose up -d. This will start all services for MISP.

  9. How will I go about setting up the initial database in MISP’s Docker environment?

    Commands such as php console/cake schema update and Migrations.Migration run all can be executed within the running MISP container through the docker compose exec misp bash -c "..." command.

  10. What should I do if my MISP containers won’t start after I ran docker compose up -d?

    Look for port conflicts with docker compose ps and check the output of docker compose logs –f to see the live log output for running services to help you find what went wrong.

  11. After installing MISP, my MISP web interface shows a blank page. What did I do wrong?

    A blank page is common due to issues with the MISP application container.Look for PHP errors or configuration issues in the container by runningdocker compose logs misp.

  12. What steps should I take to update my MISP installation within a Docker container?

    You can update by pulling new images (docker compose pull),then recreating the containers (docker compose up -d --remove-orphans),and finally executing the core MISP updates that are contained within the container.

  13. When MISP is installed through Docker, is it possible to modify MISP’s default ports?

    Yes, you can edit how MISP’s web interface is exposed by changing the port mappings in the ports section of docker-compose.yml.

  14. What command should I execute to add the first admin user after MISP installation through Docker?

    Run the command docker compose exec misp bash -c "sudo -u www-data php /var/www/MISP/app/Console/cake user add" and follow the prompts inside the container.

  15. What is the purpose of Elasticsearch when MISP is installed through Docker?

    Elasticsearch enhances MISP’s performance by offering advanced searching and indexing features for events and attributes.

  16. Can I persist MISP data after restarting my Kali Linux machine post Docker installation?

    Yes, Docker Compose implements data volumes to persist databases and files outside containers. Thus, your data is retained even after restarts.

  17. How do I backup my MISP data in Docker?

    Backup is performed by creating a copy of the database volume and the misp-docker directory, its companion files, including the .env file, and any defined data volumes.

  18. What is sudo usermod -aG docker $USER for during Docker installation?

    This command uses your current username to append you to the docker group and therefore, you can issue dockerand docker compose commands without needing to use sudo every single time.

  19. How much disk space is generally recommended to install MISP using Docker?

    At least one hundred gigabytes of SSD storage is a prerequisite.
